WHT 110/130

Horizontal machining centers
Rám stroje

Horizontal machining centres for the most demanding applications

The WHT 110/130 machines are at the cutting edge of horizontal machining. They are designed for accurate and productive machining such as drilling, thread cutting, milling or boring even large and complex workpieces. Thanks to their modularity and high degree of automation, they are the ideal solution for the energy industry, transport industry, heavy engineering and production of components for ground and construction technology.

Complete production solutions

The WHT 110/130 machines can be configured as fully-fledged machining centres with the highest technical parameters – with optional automated palette, tool and accessory change,including rotary tables and controlled milling heads. This flexibility allows you to adapt the machine for single-piece production and automated production systems.

Main benefits:

  • Exceptional accuracy and performance – extendable spindle Ø 112 mm (WHT 110) or Ø 130 mm (WHT 130) at 6,000 or 5,000 rpm; working feed up to 40 m/min.
  • Carouselling function – application of technologies for vertical turning of rotary workpieces
  • Automaton and efficiency – integration of the pallet, tool and milling head change systems, including special accessories
  • Compact installation – compact installation, space saving with the same maximum workpiece dimensions
  • Environmental standards – the machines are designed with comprehensive work media circulation and with regard to energy efficiency and reduced emissions
  • TOP TECHNICAL PARAMETERS
  • HIGH AUTOMATION LEVEL
  • FULL CAROUSEL
    APPLICATION
  • LOW MACHINE BUILD-UP AREA REQUIREMENTS
  • MEETS THE HIGHEST REQUIREMENTS FOR ECOLOGY



MACHINE CONFIGURATION

  • basic version of the "horizontal machine" in a version with a rotary table and main spindle speed up to 4,000 rpm
  • machine design of the nature of a machining centre (automatic exchange of palettes and special accessories, fully covered) with a main spindle speed of up to 6,000/5,000 rpm
  • WHT 110 machines are equipped with an extending main spindle with Ø112 mm
  • WHT 130 machines are equipped with an extending main spindle with Ø130 mm





A collection of unique technical solutions and special functions

Job management

Job management

The Job management function displays an overview of work orders and operations directly on the control panel of the machine tool, which is connected to the company's ERP system (including a desktop application for the foremen of the production hall).

High-speed extending spindle

High-speed extending spindle

The WHT 110/130 machines are equipped with centrally guided headstocks (optimal in terms of uniform heat and force load on the frame).
Remote diagnostics

Remote diagnostics

The technical means of our service is the possibility of remote connection using an Internet connection to the machine at the customer's place (we have the relevant software in the company and after enabling the service on the customer's side, we are able to connect to the machine remotely).

Modular headstock interface

Modular headstock interface

TOS VARNSDORF machines are equipped with a universal interface that allows various technological accessories to be attached to the extending spindle (in an automatic cycle). This solution also includes various types of technological accessory magazines.

Smart ergonomics

Smart ergonomics

Ingeniously designed housing and arrangement of individual nodes on the WHT 110/130 machines brings excellent ergonomics, which facilitates machine control (excellent accessibility of controls and overall operator comfort) and speeds up maintenance. Key places on the machine are quickly accessible as the covers can be easily…
TOScontrol

TOScontrol

TOScontrol is a set of applications and functions for advanced machine management.
Easy head calibration

Easy head calibration

This function automatically measures the head rotational axes using the touch probe cycle. To measure the rotary axes, a calibration ball is fixed anywhere on the machine table, which is detected using a touch probe. Based on the measured values, the system detects spatial errors resulting from axis tilting. The cycle…
Work volume monitoring

Work volume monitoring

The system allows the image from one or more cameras to be displayed on the machine control panel screen.
Headstock balancing

Headstock balancing

On TOS Varnsdorf machines the weight of the headstock is balanced (depending on the machine type) by means of counterweights inside the column or by means of a hydromechanical system.

Spindle precision enhancement

Spindle precision enhancement

This function makes it possible to compensate for the temperature expansion of the main spindle, which is caused by a change in the temperature of the spindle during long-term load and when ambient temperatures change.

Integrated metrological system

Integrated metrological system

Integration of a metrology system (3D coordinate measuring machine) with a touch probe into the machine tool, thanks to which it is possible to precisely measure workpieces directly on the machine.
